Hanwha Techwin QND-6021 2MP PoE Indoor Mini Dome IP Security Camera 4mm Lens
Hanwha Techwin QND-6021 2MP PoE Indoor Mini Dome IP Security Camera 4mm Lens
Hanwha Techwin QND-6021 2MP PoE Indoor Mini Dome Network IP Security Camera
QND-6021
2MP H.265 NW Dome Camera(Q mini)
• 4mm fixed lens
• 0.03Lux (Color), WDR (120dB)
• Max. 30fps@2MP (H.265 / H.264)
• H.265, H.264, MJPEG codec support, Multiple streaming
• Tampering, Motion detection, Defocus detection
• Micro SD / SDHC / SDXC memory slot (Max. 128GB)
• Hallway view, WiseStream II support
• LDC, PoE
Product Specification
Video
Imaging Device
1/2.8" 2MP CMOS
Resolution
1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360
Max. Framerate
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 15fps/12fps(60Hz/50Hz)
Min. Illumination
Color: 0.03Lux(F1.6, 1/30sec)
Lens
Focal Length (Zoom Ratio)
4.0mm fixed focal
Max. Aperture Ratio
F1.6
Angular Field of View
H: 87.6 / V: 46.4° / D: 104.5°
Focus Control
Fixed
Pan / Tilt / Rotate
Pan / Tilt / Rotate Range
0°~350° / 0°~69° / 0°~355°
Operational
Camera Title
Displayed up to 85 characters
Day & Night
Auto(Electrical)
Backlight Compensation
BLC, WDR, SSDR
Wide Dynamic Range
120dB
Digital Noise Reduction
SSNR
Motion Detection
4ea, polygonal zones
Privacy Masking
6ea, rectangular zones
Gain Control
Low / Middle / High
White Balance
ATW / AWC / Manual / Indoor / Outdoor
LDC
Support
Electronic Shutter Speed
Minimum / Maximum / Anti flicker (1/5~1/12,000sec)
Video Rotation
Flip, Mirror, Hallway view(90°/270°)
Analytics
Defocus detection, Motion detection, Tampering
Business Intelligence
People counting
Alarm Triggers
Analytics, Network disconnect
Alarm Events
File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC or NAS recording at event triggers
Network
Ethernet
RJ-45(10/100BASE-T)
Video Compression
H.265/H.264: Main/High, MJPEG
Smart Codec
WiseStreamⅡ
Bitrate Control
H.264/H.265: CBR or VBR
MJPEG: VBR
Streaming
Unicast(6 users) / Multicast
Multiple streaming(Up to 3 profiles)
Protocol
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP
Security
HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access log
802.1X Authentication(EAP-TLS, EAP-LEAP)
Application Programming Interface
ONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platform
General
Webpage Language
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch
Web Viewer
Supported OS: Windows 7, 8.1, 10, Mac OSx10.12, 10.13, 10.14
Recommended Browser: Google Chrome
Supported Browser: MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OSxonly)
Edge Storage
Micro SD/SDHC/SDXC 1slot 128GB
Memory
512MB RAM, 256MB Flash
Environmental & Electrical
Operating Temperature / Humidity
-10°C ~ +55°C(-14°F ~ +131°F) / Less than 90% RH
Storage Temperature / Humidity
-30°C ~ +60°C(-22°F ~ +140°F) / Less than 90% RH
Certification
IP42, IK08
Input Voltage
PoE(IEEE802.3af, Class2)
Power Consumption
PoE: Max 4.80W, typical 2.80W
Mechanical
Color / Material
White / Plastic
RAL Code
RAL9003
Product Dimensions / Weight
Ø99.0x56.0mm(Ø3.9x2.2"), 145g(0.32 lb)
DORI (EN62676-4 standard)
Detect (25PPM/ 8PPF)
40.0m(131.36ft)
Observe (63PPM/ 19PPF)
16.0m(52.54ft)
Recognize (125PPM/ 38PPF)
8.0m(26.27ft)
Identify (250PPM/ 76PPF)
4.0m(13.14ft)
- • Design and specifications are subject to change without notice.
• Wisenet is the proprietary brand of Hanwha Techwin, formerly known as Samsung Techwin.
Video Imaging Device 1/2.8" 2MP CMOS Resolution 1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360 Max. Framerate H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 15fps/12fps(60Hz/50Hz)Min. Illumination Color: 0.03Lux(F1.6, 1/30sec) Lens Focal Length (Zoom Ratio) 4.0mm fixed focal Max. Aperture Ratio F1.6 Angular Field of View H: 87.6 / V: 46.4° / D: 104.5° Focus Control Fixed Pan / Tilt / Rotate Pan / Tilt / Rotate Range 0°~350° / 0°~69° / 0°~355° Operational Camera Title Displayed up to 85 characters Day & Night Auto(Electrical) Backlight Compensation BLC, WDR, SSDR Wide Dynamic Range 120dB Digital Noise Reduction SSNR Motion Detection 4ea, polygonal zones Privacy Masking 6ea, rectangular zones Gain Control Low / Middle / High White Balance ATW / AWC / Manual / Indoor / Outdoor LDC Support Electronic Shutter Speed Minimum / Maximum / Anti flicker (1/5~1/12,000sec) Video Rotation Flip, Mirror, Hallway view(90°/270°) Analytics Defocus detection, Motion detection, Tampering Business Intelligence People counting Alarm Triggers Analytics, Network disconnect Alarm Events File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC or NAS recording at event triggersNetwork Ethernet RJ-45(10/100BASE-T) Video Compression H.265/H.264: Main/High, MJPEG Smart Codec WiseStreamⅡ Bitrate Control H.264/H.265: CBR or VBR
MJPEG: VBRStreaming Unicast(6 users) / Multicast
Multiple streaming(Up to 3 profiles)Protocol IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP Security HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access log
802.1X Authentication(EAP-TLS, EAP-LEAP)Application Programming Interface ONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platformGeneral Webpage Language English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch Web Viewer Supported OS: Windows 7, 8.1, 10, Mac OSx10.12, 10.13, 10.14
Recommended Browser: Google Chrome
Supported Browser: MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OSxonly)Edge Storage Micro SD/SDHC/SDXC 1slot 128GB Memory 512MB RAM, 256MB Flash Environmental & Electrical Operating Temperature / Humidity -10°C ~ +55°C(-14°F ~ +131°F) / Less than 90% RH Storage Temperature / Humidity -30°C ~ +60°C(-22°F ~ +140°F) / Less than 90% RH Certification IP42, IK08 Input Voltage PoE(IEEE802.3af, Class2) Power Consumption PoE: Max 4.80W, typical 2.80W Mechanical Color / Material White / Plastic RAL Code RAL9003 Product Dimensions / Weight Ø99.0x56.0mm(Ø3.9x2.2"), 145g(0.32 lb) DORI (EN62676-4 standard) Detect (25PPM/ 8PPF) 40.0m(131.36ft) Observe (63PPM/ 19PPF) 16.0m(52.54ft) Recognize (125PPM/ 38PPF) 8.0m(26.27ft) Identify (250PPM/ 76PPF) 4.0m(13.14ft) - • Design and specifications are subject to change without notice.
• Wisenet is the proprietary brand of Hanwha Techwin, formerly known as Samsung Techwin.
