Hanwha Techwin HCZ-6321 2MP 32x AHD Zoom Box Security Camera 4.44~142.6mm Lens
HCZ-6321
2MP 32x AHD Zoom Camera
• Max. 2MP resolution
• Min. Illumination 0.2 Lux@F1.6 (Color), 0.01 Lux@F1.6 (B/W)
• 4.44 ~ 142.6mm (32x) optical zoom, 16x digital zoom
• Digital PTZ
• Day & Night (Auto ICR), WDR (120dB)
• Detection, Tracking, Fixed Moved, Tampering support
• Min. Illumination 0.2 Lux@F1.6 (Color), 0.01 Lux@F1.6 (B/W)
• 4.44 ~ 142.6mm (32x) optical zoom, 16x digital zoom
• Digital PTZ
• Day & Night (Auto ICR), WDR (120dB)
• Detection, Tracking, Fixed Moved, Tampering support
Product Specification
Video
Imaging Device
1/2.8" CMOS
Resolution
1080p
Max. Framerate
30fps/25fps(60Hz/50Hz)
Min. Illumination
Color: 0.2 Lux (1/30sec, F1.6)
B/W: 0.01 Lux (1/30sec, F1.6)
Video Out
AHD: 1080p, BNC
CVBS: SD, DIP connector type
Video Transmission Distance
500m(5C2V Coaxial Cable)
Lens
Focal Length (Zoom Ratio)
4.44~142.6mm(32x) zoom
Max. Aperture Ratio
F1.6(Wide)~F4.4(Tele)
Angular Field of View
H: 62.8°(Wide)~2.23°(Tele) / V: 36.80°(Wide)~1.26°(Tele)
Min. Object Distance
1.5m(4.92ft)
Focus Control
Auto, Manual, Oneshot AF
Lens Type
DC auto iris
Operational
Camera Title
Displayed up to 15 characters
Day & Night
Auto(ICR)
Backlight Compensation
BLC, HLC, WDR, SSDR
Wide Dynamic Range
120dB
Digital Noise Reduction
SSNRⅢ
Digital Image Stabilization
Support
Defog
Support
Motion Detection
4ea, rectangular zones
Privacy Masking
12ea, rectangular zones
Gain Control
Low / Middle / High
White Balance
ATW / AWC / Manual / Indoor / Outdoor
Electronic Shutter Speed
Minimum / Maximum / Anti flicker (2 ~ 1/33,000sec)
Digital PTZ
Support
Video Rotation
H-REV/V-REV
Analytics
Motion detection
Serial Interface
RS-485: Samsung-T/E, Pelco-D/P, Panasonic, Bosch, AD, Vicon, Honeywell
Alarm I/O
Output 1ea
Coaxial Protocol
ACP(AHD Coax Protocol)
Environmental & Electrical
Operating Temperature / Humidity
-10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH
Storage Temperature / Humidity
-10°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
Input Voltage
12V DC
Power Consumption
Max 6W
Mechanical
Color / Material
Black / Metal
Product Dimensions / Weight
72(W)x63.9(H)x137.25(D)mm(2.83x2.52x5.40"), 451g(0.99 lb)
DORI (EN62676-4 standard)
Detect (25PPM/ 8PPF)
Wide: 62.9m(206.4ft) / Tele: 1973m(6473.05ft)
Observe (63PPM/ 19PPF)
Wide: 25.2m(82.56ft) / Tele: 789.2m(2589.22ft)
Recognize (125PPM/ 38PPF)
Wide: 12.6m(41.28ft) / Tele: 394.6m(1294.61ft)
Identify (250PPM/ 76PPF)
Wide: 6.3m(20.64ft) / Tele: 197.3m(647.31ft)
- • Design and specifications are subject to change without notice.
• Wisenet is the proprietary brand of Hanwha Techwin, formerly known as Samsung Techwin.
