Hanwha Techwin Wisnet XRN-410S-2TB HDD 4CH 4K 8MP PoE+ NVR IP Security Recorder
Hanwha Techwin Wisnet XRN-410S-2TB HDD 4CH 4K 8MP PoE+ NVR IP Security Recorder
Hanwha Techwin WiseNet XRN-410S-2TB HDD 4CH 4K 8MP PoE+ NVR IP Security Recorder
XRN-410S-2TB
4CH 8M H.265 NVR with PoE+ Switch
• H.265, H.264, MJPEG codec support,
• WiseStream support
• 50Mbps network camera recording
• Plug & play by 4 PoE/PoE+ ports
• Max. 1HDD supported
• HDMI / VGA local monitor
• ARB supported
• P2P service(QR code connect) support
Product Spec
Display
Network camera
Inputs
Max. 4CH
Resolution
8MP ~ CIF
Protocols
Wisenet, ONVIF
Decoding
Local Display
[Clone Display]
HDMI: 3840 x 2160, 1920x1080, 1280x720
VGA: 1920x1080, 1280x720
Resolution
8MP(60fps), 5MP(90fps), 3MP(120fps), 2MP(240fps), 720p(240fps), D1(240fps)
Performance
Record
Compression
H.265, H.264, MJPEG
Recording Bandwidth
Max. 50Mbps
Resolution
8MP ~ CIF
Mode
Normal, Schedule(Continuous/Event), Event (Pre/Post)
Event Trigger
Alarm Input, Video Loss, Camera Event(Alarm, MD, Video Analytics, Defocus)
Event Action
e-Mail, PTZ Preset, Alarm Out, Buzzer, Monitor Out
Search & Play
Playback Bandwidth
Max. 32Mbps(4CH simultaneously)
User
Max. 4 Users (Local 1, Remote 3)
Simultaneous playback
Max. 4CH(Local Monitor, Network)
Fisheye Dewarping
WEB / CMS
Storage
Supported HDD
Up to 6TB
HDD Slot
SATA 1ea(Max. 6TB)
Backup
File backup
BU/Exe(GUI), JPG/AVI(Network)
Function
Multi channel(Upto 4CH) Play, Date-Time/Title display
Network
Protocol
IPv4, IPv6, TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client), PPPoE, SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF (Profile-S), SUNAPI(Server, Client)
DDNS
Wisenet DDNS
Transmission Bandwidth
Max. 64Mbps
Audio
Input/Output
4 CH(network)
Compression
G.711, G.726, AAC(16/48KHz)
Audio Communication
2-Way
Max Remote Users
Search(3), Live Unicast(10), Multicast(20)
Security
IP address filtering, User access Log, 802.1x, Encryption
Web viewer
Supported OS
Windows 7, 8, 10, Mac OS X 10.9. 10.10. 10.11
Supported browser
Plug-in free web viewer
- Supported Browser: Google Chrome 47, MS Edge 20
Plug-in Webviewer
- Supported MS Explore 11, Apple Safari 9 * Mac OS X only
Viewer Software
SSM, Webviewer, Smart Viewer, Wisenet mobile
Support SDK/CGI(SUNAPI) for integration to 3'rd party VMS
Functions
Camera Setup
Item
IP address, Add profile edit, Bitrate, Compression, GOP, Quality, Camera MD setup
Camera video setup (Simple focus, Brightness/Contrast, Flip/Mirror, IRIS, WDR, D&N, SSNR, Shutter, SSDR, DIS), Fisheye Dewarping Mode, Hallway View Setup, Camera Webpage
PTZ
Control
Via GUI, Webviewer, SPC-2000
Smart phone
Support Model
iOS, Android
Protocol Support
RTP, RTSP, HTTP, CGI(SUNAPI)
Control
Live(Multi-Profile Support), Playback
Max. Remote Users
Search(3), Live Unicast(10)
Redundancy
ARB
Support
Easy configuration
P2P(QR code)
Interface
HDMI
1EA
VGA
1EA
e-SATA
1EA
Audio
Out(1EA, RCA, Line)
Ethernet
RJ-45(10/100/1000BASE-T) x 1
RJ-45(PoE+) x 4
Alarm
In 4EA, Out 2EA
USB
2EA(Front 1, Rear 1)
System
System Control
Mouse, IR remocon, Web, Controller (SPC-2000)
Language
English, French, German, Italian, Spanish, Russian, Turkish, Polish, Dutch, Swedish, Czech, Portuguese, Danish, Rumanian, Serbian, Croatian, Hungarian, Greek, Norwegian, Finnish, Korean, Chinese, Japanese, Thai
Environmental
Operating Temperature
0°C to +40°C(32℉ to 104℉)
Operating Humidity
20% ~ 85% RH
Electrical
Power Input
54V DC / 1.67A
Power Consumption
MAX. 13W (44BTU, 2TB HDD x 1ea)
PoE Budget
Max. 50W
Mechanical
Color / Material
Black / Metal
Dimension (WxHxD)
W300 x H47 x D208.7mm (18.1”X1.85”X8.22”) (1U)
Weight
1.694Kg
- • Design and specifications are subject to change without notice.
• Wisenet is the proprietary brand of Hanwha Techwin, formerly known as Samsung Techwin.
